FG Gubellini FSM11 Rear Shock Absorber for Honda CBR 600 RR 2007–2018 HON090FSM114600
  • FG Gubellini FSM11 Rear Shock Absorber for Honda CBR 600 RR 2007–2018 HON090FSM114600

FG Gubellini FSM11 Rear Shock Absorber for Honda CBR 600 RR 2007–2018 HON090FSM114600

HON090FSM114600

FG Gubellini FSM11 rear shock with external reservoir and 4 adjustments. Ideal for Honda CBR 600 RR 2007–2018, road and racing use.

€1,182.18
€886.64 Save 25%
Tax included
Quantity
MADE TO ORDER PRODUCT 10 WORKING DAYS

Description

The FG Gubellini FSM11 rear shock absorber part number HON090FSM114600 represents FG’s sport performance range, designed to deliver high performance both on road and track.

It is an oleopneumatic shock absorber with an external gas reservoir, rigidly fixed to the body, ensuring stability, precision and consistent performance even under extreme conditions.

With 4 external adjustments, it allows full customization based on rider needs:

  • Length adjustment (+/- 9 mm)
  • Hydraulic rebound adjustment (40 clicks)
  • Hydraulic compression adjustment (40 clicks)
  • Spring preload adjustment (lockring system)

Built using high-quality materials such as 7075 aluminum (Ergal) and steel, machined from solid, it guarantees durability and long-term reliability.

The thermally calibrated piston system ensures consistent performance even after extended use and high temperatures, while the oversized nitrogen reservoir improves pressure stability.

Each shock is designed using advanced 3D modeling and can be customized on request based on rider weight, height and riding style.

Compatibility:

  • Honda CBR 600 RR (2007 – 2018)

Main features:

  • FG Gubellini FSM11 rear shock
  • Product code: HON090FSM114600
  • Oleopneumatic structure with external reservoir
  • 4 fully adjustable settings
  • Materials: 7075 aluminum (Ergal) and steel
  • FG modular system
  • Ideal for sport, road and racing use

Technical specifications:

  • Piston: Ø 46 mm
  • Rod: Ø 14 mm
  • Spring: linear
  • Structure: twin-body
  • External gas reservoir
  • Weight: 10 kg
  • Dimensions: 30 x 70 x 30 cm

Technologies:

  • Advanced 3D design
  • Thermally calibrated piston
  • Precision CNC machining
  • FG modular system
  • Enlarged reservoir for thermal stability
Product Details
HON090FSM114600

Data sheet

Application
Moto
Compatible with
Honda
Engine type
4 stroke
Displacement
600 cc
Model
CBR
Model
RR
