Malossi Rs24 rear shock absorber 4620159
Malossi code: 4620159
Malossi rear shock absorber Rs24, wheelbase 333 mm for 10" wheel.
The versatility of this suspension has proven surprising thanks to the 3 new adjustment systems, which enhance its use on the road and track:
-adjustment of the hydraulic system in extension to absorb all the roughness of the terrain;
-double regulation of the hydraulic compression system (separate for low and high speed);
-spring preload to adapt the vehicle's running position;
- setup variation system for cornering behaviour.
Technical features
These special shock absorbers have technical characteristics that represent the maximum technological expression available on the market today:
-Type: hydropneumatic shock absorber with separate compensation tank
-Use: racing scooter
-Shock absorber rod diameter 14 mm in hardened and tempered 38 NiCrMo4UNI 7845 steel with hard chrome deposit 25-30 micron thick (surface hardness of the shaft not yet treated HRC 55/60)
-Piston diameter 36 mm with two independent disc packs, one in compression and one in extension
-New lamellar system in harmonic steel which allows for very precise calibration
-Piston guide shoe of the LUBRIFLON-PTFEB70 type (bronze filled modified compound)
- Sliding on DU GUIDE bush (compound obtained by sintering a state of spheroidal bronze on a suitably pressed mild steel strip and with subsequent impregnation and coating with a mixture of PTFE+FB)
- Scraper ring in SEALTHANE grade 9345 polyester resin
-Micrometic adjustment of spring pre-load via ring nuts
-Adjustment of hydraulic braking in extension pre-selectable on approximately 24 positions
-Double adjustment of the hydraulic compression braking, pre-selectable on approximately 10 positions each, separate for low and high speed
-Special oil with low viscosity and practically insensitive to temperature variations
-External compensation tank which allows an increase in the quantity of internal fluids
- Wheelbase adjustment of 25 mm (only for rear shock absorber)
- Wheelbase: rear 333 + 25 mm - front 181 mm
-Stroke: rear 62 mm - front 45 mm
