Pair of front and rear shock absorbers Malossi Rs24 4614479 for Piaggio
Malossi code: 4620162
Pair of Malossi shock absorbers, front wheelbase 181 mm and rear wheelbase 333 mm
10" tire shock absorbers
These special shock absorbers have technical characteristics that represent the maximum technological expression available on the market today:
-Type: hydropneumatic shock absorber with separate compensation tank
-Use: racing scooter
-Shock absorber rod Ø 14 mm in 38 NiCrMo4UNI 7845 hardened and tempered steel with hard chrome deposit 25-30 micron thick (surface hardness of the shaft not yet treated HRC 55/60)
-Piston Ø 36 mm with two independent disc packs, one in compression and one in extension
-New lamellar system in harmonic steel which allows for very precise calibration
-Piston guide shoe of the LUBRIFLON-PTFEB70 type (bronze filled modified compound)
- Sliding on DU GUIDE bush (compound obtained by sintering a state of spheroidal bronze on a suitably pressed mild steel strip and with subsequent impregnation and coating with a mixture of PTFE+FB)
- Scraper ring in SEALTHANE grade 9345 polyester resin
-Micrometic adjustment of spring pre-load via ring nuts
-Adjustment of hydraulic braking in extension pre-selectable on approximately 24 positions
-Double adjustment of the hydraulic compression braking, pre-selectable on approximately 10 positions each, separate for low and high speed
-Special oil with low viscosity and practically insensitive to temperature variations
-External compensation tank which allows an increase in the quantity of internal fluids
- Wheelbase adjustment of 25 mm (only for rear shock absorber)
- Wheelbase: rear 333 + 25 mm - front 181 mm
-Stroke: rear 62 mm - front 45 mm
