Dellorto PHDG 19 09853 Carburetor

The Dellorto PHBD 19 carburetor is a benchmark component for two-stroke enthusiasts. Designed with a Ø19 mm diffuser, it is optimized to ensure a high flow coefficient and increased air flow, resulting in a significant increase in power and responsiveness.

The body, float chamber, and throttle valve are made of aluminum alloy, ensuring lightweight construction and effective heat dissipation. The aluminum throttle valve receives a special surface treatment that increases smoothness and wear resistance.

Among its main features:

Vacuum intake and oil inlet connection with safety valve.

Adjustable calibration thanks to the idle mixture screw and the possibility of adjusting the fuel inlet seat.

Easily replaceable main and idle jets to adapt to different engine configurations.

Lightweight and racing finish with anodized throttle valve cover and float chamber cap.

This carburetor is ideal for tuning scooters and 2-stroke motorcycles, where a prompt response and an overall improvement in performance are sought.
