Ohvale gp-0 Evo 110cc 4t automatic, with electric start.
Ohvale gp-0 evo 110 automatic 2026 technical sheet:
ENGINE TYPE: ZS 110 cc Horizontal single cylinder, 4 stroke, Air cooled.
DISTRIBUTION: Single camshaft, SOHC - 2 valves.
FUEL: Unleaded petrol (N.O. min 95).
BORE X STROKE: 52.4mm x 49.5mm.
DISPLACEMENT: 106.7 cc.
FUEL SYSTEM: KF PZ19 carburetor (valve section 13-18), Racing air filter.
IGNITION: Electronic, with spark plug and external coil.
STARTER: Electric.
EXHAUST: Stainless steel exhaust. Arrow titanium under-seat single silencer. Ready for DB Killer.
LUBRICATION: Wet sump lubrication system, with oil radiator. Oil quantity: 0.9 L.
GEARBOX: Automatic | Setting Ohvale.
PRIMARY TRANSMISSION: Gears.
SECONDARY TRANSMISSION: Regina gold series chain. Ratio 17/32 (1.882).
CLUTCH: Centrifugal.
FRAME: High-strength steel tubular trellis, robotized welding (New config. 2026).
FRONT SUSPENSION: Upside down fork with Ø 33mm stanchions and CNC feet. K6-K8 wheel configuration.
REAR SUSPENSION: Aluminum swingarm. Piggy-back monoshock. Fully adjustable: hydraulic compression and extension, spring preload and wheelbase. K 140 spring configuration.
FOOTREST: CNC machined parts.
FRONT BRAKING SYSTEM: Single disc Ø 180mm. Formula monobloc radial caliper (4 D24 pistons). Axial pump with integrated reservoir and metal braided hose.
REAR BRAKE SYSTEM: Single disc Ø 155mm. Formula radial caliper (2 D24 pistons). Pump with integrated reservoir and metal braided hose.
RIMS: Aluminum alloy rims, Ohvale design. Front 2.50" x 10" - Rear 3.00" x 10".
TIRES: Pirelli slick tubeless. Front 100/80 - 10", Rear 120/80 - 10".
FAIRINGS: Fiberglass racing fairing + New 2026 graphic design.
DIMENSIONS (DEFAULT SETTING): Max length: 1478mm / max width: 630mm (at the semi-handlebars). Max height: 790mm / Seat height: 695mm.
DRY WEIGHT: 67 Kg (without any fluid).
TANK CAPACITY: 3.5 Liters.
