Ohvale gp-0 110cc Evo 4t 4 marce 2026.
Technical sheet Ohvale gp-0 110 cc Evo 4S MY26:
ENGINE TYPE: ZS 110 cc Horizontal single cylinder, 4T, Air cooled.
DISTRIBUTION: Single camshaft, SOHC - 2 valves.
FUEL: Unleaded petrol (N.O. min 95).
BORE X STROKE: 54mm x 49.5mm.
DISPLACEMENT: 113.3 cc.
FUEL SYSTEM: DELLORTO PHBL 24 BD Setting Ohvale carburetor, Racing air filter.
IGNITION: Electronic, with spark plug and external coil (CDI with rev limiter).
STARTER: Kick starter with auto decompression device.
EXHAUST: Stainless steel exhaust. Arrow titanium under-seat mono silencer. Ready for DB Killer.
LUBRICATION: Wet sump lubrication system, with oil radiator. Oil quantity: 0.8 L.
GEARBOX: 4 close-ratio N-1-2-3-4.
PRIMARY TRANSMISSION: Gears.
SECONDARY TRANSMISSION: Regina gold series chain. Ratio 16/35 (2.187).
CLUTCH: In oil bath with 4 discs.
FRAME: Tubular trellis in high-strength steel, robotized welding (New config. 2026).
FRONT SUSPENSION: Upside down fork with Ø 33mm stems and CNC feet. K6-K6 grinding wheel config.
REAR SUSPENSION: Aluminum swingarm. Piggy-back monoshock. Fully adjustable: hydraulic compression and extension, spring preload and wheelbase. K140 spring config.
FOOTREST: CNC machined parts.
FRONT BRAKING SYSTEM: Single disc Ø 180mm. Formula monobloc radial caliper (4 D25 pistons). Sintered pads. Axial pump with integrated reservoir and metal braided hose.
REAR BRAKING SYSTEM: Single disc Ø 155mm. Formula radial caliper (2 D25 pistons). Pump with integrated reservoir and metal braided hose.
RIMS: Aluminum alloy rims, Ohvale design. Front 2.50" x 10" - Rear 3.00" x 10".
TIRES: Pirelli slick tubeless. Front 100/80 - 10", Rear 120/80 - 10".
FAIRINGS: Fiberglass racing fairing + New 2026 graphic design.
DIMENSIONS (DEFAULT SETTING): Max length: 1500mm / Max width: 740mm (at the semi-handlebars). Max height: 810mm / Seat height: 695mm.
DRY WEIGHT: 64 Kg (without any liquid).
TANK CAPACITY: 3.5 Liters.
